Bring Your Own Delegation Token

Instead of creating a proxy user and giving it access to HDFS for use with doAs, you can give Vertica a Hadoop delegation token to use. You must obtain this delegation token from the Hadoop NameNode. In this model, security is handled entirely on the Hadoop side, with Vertica just passing along a token. Vertica may or may not be Kerberized.

A typical workflow is:

  • In an ETL front end, a user submits a query.
  • The ETL system uses authentication and authorization services to verify that the user has sufficient permission to run the query.
  • The ETL system requests a delegation token for the user from the NameNode.
  • The ETL system makes a client connection to Vertica, sets the delegation token for the session, and runs the query.

When using a delegation token, clients can connect as any Vertica user. No proxy user is required.

In the following illustration, Bob and Carol have Hadoop-issued delegation tokens. They connect to Vertica and Vertica uses those delegation tokens to access files in HDFS.

Session Configuration

Set the HadoopImpersonationConfig session parameter to specify the delegation token and HDFS cluster. Vertica will access HDFS using that delegation token until the session ends, the token expires, or you change the parameter.

The value of this session parameter is a collection of JSON objects. Each object specifies a delegation token ("token") in webhdfs format and an HDFS nameservice or namenode. HadoopImpersonationConfig Format describes the full JSON syntax.

The following example shows access on behalf of two different users. The users "stephanie" and "bob" are Hadoop users, not Vertica users. "dbuser1" is a Vertica user with no special privileges.

$ vsql -U dbuser1

=> ALTER SESSION SET
   HadoopImpersonationConfig ='[{"authority":"hadoop1:50070","token":"JAAGZGJldGwxBmRiZXRsMQCKAWDXJgB9igFg-zKEfY4gao4BmhSJYtXiWqrhBHbbUn4VScNg58HWQxJXRUJIREZTIGRlbGVnYXRpb24RMTAuMjAuMTAwLjU0OjgwMjA"}]';
=> COPY nation FROM 'hdfs:///user/stephanie/nation.dat';

=> ALTER SESSION SET
   HadoopImpersonationConfig ='[{"authority":"hadoop1:50070","token":"HgADdG9tA3RvbQCKAWDXJgAoigFg-zKEKI4gaI4BmhRoOUpq_jPxrVhZ1NSMnodAQnhUthJXRUJIREZTIGRlbGVnYXRpb24RMTAuMjAuMTAwLjU0OjgwMjA"}]';
=> COPY nation FROM 'hdfs:///user/bob/nation.dat';

You can use the WebHDFS REST API to get delegation tokens:

$ curl -s --noproxy "*" --negotiate -u: -X GET "http://hadoop1:50070/webhdfs/v1/?op=GETDELEGATIONTOKEN"

Vertica does not, and cannot, renew delegation tokens when they expire. You must either keep sessions shorter than token lifetime or implement a renewal scheme.

Delegation Tokens and the HCatalog Connector

HiveServer2 uses a different format for delegation tokens. To use the HCatalog Connector, therefore, you must set two delegation tokens, one as usual (authority) and one for HiveServer2 (schema). The HCatalog Connector uses the schema token to access metadata and the authority token to access data. The schema name is the same Hive schema you specified in CREATE HCATALOG SCHEMA. The following example shows how to use these two delegation tokens.

$ vsql -U dbuser1

-- set delegation token for user and HiveServer2
=> ALTER SESSION SET
   HadoopImpersonationConfig='[
     {"nameservice":"hadoopNS","token":"JQAHcmVsZWFzZQdyZWxlYXNlAIoBYVJKrYSKAWF2VzGEjgmzj_IUCIrI9b8Dqu6awFTHk5nC-fHB8xsSV0VCSERGUyBkZWxlZ2F0aW9uETEwLjIwLjQyLjEwOTo4MDIw"},
     {"schema":"access","token":"UwAHcmVsZWFzZQdyZWxlYXNlL2hpdmUvZW5nLWc5LTEwMC52ZXJ0aWNhY29ycC5jb21AVkVSVElDQUNPUlAuQ09NigFhUkmyTooBYXZWNk4BjgETFKN2xPURn19Yq9tf-0nekoD51TZvFUhJVkVfREVMRUdBVElPTl9UT0tFThZoaXZlc2VydmVyMkNsaWVudFRva2Vu"}]';

-- uses HiveServer2 token to get metadata
=> CREATE HCATALOG SCHEMA access WITH hcatalog_schema 'access';

-- uses both tokens
=> SELECT * FROM access.t1;

--uses only HiveServer2 token
=> SELECT * FROM hcatalog_tables;

HiveServer2 does not provide a REST API for delegation tokens like WebHDFS does. See Getting a HiveServer2 Delegation Token for some tips.

Testing the Configuration

You can use the HADOOP_IMPERSONATION_CONFIG_CHECK function to test your HDFS delegation tokens and HCATALOGCONNECTOR_CONFIG_CHECK to test your HCatalog Connector delegation token.
